| Input (DC) |
|
| Max. PV input voltage |
1000 V |
| Min. PV input voltage / Startup input voltage |
200 V / 250 V |
| Nominal input voltage |
585 V |
| MPP voltage range |
200 - 1000 V |
| MPP voltage range for nominal power |
500 - 850 V |
| No. of independent MPP inputs |
3 |
| Max. number of PV strings per MPPT |
3 / 3 / 2 |
| Max. PV input current |
88 A (33 A / 33 A / 22 A) |
| Max. current for input connector |
12 A |
| Max. DC short-circuit current |
96 A (36 A / 36 A / 24 A) |
| Output (AC) |
|
| Nominal AC power (at 50 °C) |
33000 W |
| Max. AC output at PF=1 (at 45 °C) |
36000 W |
| Max. AC apparent power (at 45 °C) |
36000 VA |
| Max. AC output current |
53.5 A |
| Nominal AC voltage |
3 / PE or 3 / N / PE, 230 / 400 V |
| AC voltage range |
310 - 480 V |
| Nominal grid frequency / Grid frequency range |
50 Hz / 45 - 55 Hz, 60 Hz / 55 - 65 Hz |
| THD |
< 3 % (at nominal power) |
| DC current injection |
< 0.5 % In |
| Power factor at nominal power / Adjustable power factor |
> 0.99 / 0.8 leading - 0.8 lagging |
| Feed-in phases / Connection phases |
3 / 3 |
| Efficiency |
|
| Max. efficiency / Euro. efficiency |
98.5 % / 98.3 % |
| Protection |
|
| DC reverse connection protection |
Yes |
| AC short-circuit protection |
Yes |
| Leakage current protection |
Yes |
| Grid monitoring |
Yes |
| DC switch / AC switch |
Yes / No |
| DC fuse |
Yes (positive, 15A) |
| PV string current monitoring |
Yes |
| Overvoltage protection |
DC Type II / AC Type II |
| General Data |
|
| Dimensions (W*H*D) |
525*740*240 mm |
| Weight |
48 kg |
| Isolation method |
Transformerless |
| Degree of protection |
IP65 |
| Night power consumption |
< 2 W |
| Operating ambient temperature range |
-25 to 60 °C(> 50 °C derating) |
| Allowable relative humidity range (non-condensing) |
0 - 100 % |
| Cooling method |
Smart forced air cooling |
| Max. operating altitude |
4000 m(> 3000 m derating) |
| Display / Communication |
Graphic LCD / RS485 |
| DC connection type |
MC4 (Max. 6 mm² ) |
| AC connection type |
Screw clamp terminal (Max. 50 mm² ) |
| Compliance |
CEA, IEC 62109, IEC 61727, IEC 62116, IEC 60068, IEC 61683, CE, IEC 61000-3-11/-12, VDE 0126-1-1, VDE-AR-N-4105 |
| Grid support |
LVRT, HVRT, active & reactive power control and power ramp rate control |
