Input (DC) |
|
Max. PV input voltage |
1000 V |
Min. PV input voltage / Startup input voltage |
200 V / 250 V |
Nominal input voltage |
585 V |
MPP voltage range |
200 - 1000 V |
MPP voltage range for nominal power |
500 - 850 V |
No. of independent MPP inputs |
3 |
Max. number of PV strings per MPPT |
3 / 3 / 2 |
Max. PV input current |
88 A (33 A / 33 A / 22 A) |
Max. current for input connector |
12 A |
Max. DC short-circuit current |
96 A (36 A / 36 A / 24 A) |
Output (AC) |
|
Nominal AC power (at 50 °C) |
33000 W |
Max. AC output at PF=1 (at 45 °C) |
36000 W |
Max. AC apparent power (at 45 °C) |
36000 VA |
Max. AC output current |
53.5 A |
Nominal AC voltage |
3 / PE or 3 / N / PE, 230 / 400 V |
AC voltage range |
310 - 480 V |
Nominal grid frequency / Grid frequency range |
50 Hz / 45 - 55 Hz, 60 Hz / 55 - 65 Hz |
THD |
< 3 % (at nominal power) |
DC current injection |
< 0.5 % In |
Power factor at nominal power / Adjustable power factor |
> 0.99 / 0.8 leading - 0.8 lagging |
Feed-in phases / Connection phases |
3 / 3 |
Efficiency |
|
Max. efficiency / Euro. efficiency |
98.5 % / 98.3 % |
Protection |
|
DC reverse connection protection |
Yes |
AC short-circuit protection |
Yes |
Leakage current protection |
Yes |
Grid monitoring |
Yes |
DC switch / AC switch |
Yes / No |
DC fuse |
Yes (positive, 15A) |
PV string current monitoring |
Yes |
Overvoltage protection |
DC Type II / AC Type II |
General Data |
|
Dimensions (W*H*D) |
525*740*240 mm |
Weight |
48 kg |
Isolation method |
Transformerless |
Degree of protection |
IP65 |
Night power consumption |
< 2 W |
Operating ambient temperature range |
-25 to 60 °C(> 50 °C derating) |
Allowable relative humidity range (non-condensing) |
0 - 100 % |
Cooling method |
Smart forced air cooling |
Max. operating altitude |
4000 m(> 3000 m derating) |
Display / Communication |
Graphic LCD / RS485 |
DC connection type |
MC4 (Max. 6 mm² ) |
AC connection type |
Screw clamp terminal (Max. 50 mm² ) |
Compliance |
CEA, IEC 62109, IEC 61727, IEC 62116, IEC 60068, IEC 61683, CE, IEC 61000-3-11/-12, VDE 0126-1-1, VDE-AR-N-4105 |
Grid support |
LVRT, HVRT, active & reactive power control and power ramp rate control |
